Thermal Imaging Riflescope Hybrid Series- HYH75W
Thermal Imaging Riflescope Hybrid Series- HYH75W

Thermal Imaging Riflescope Hybrid Series- HYH75W

Thermal Imaging Riflescope Hybrid Series- HYH75W

The HYBRID HYH75W fuses the capabilities of a thermal clip-on and a thermal riflescope to create a new breed of thermal device. The HYBRID gives you never-before-seen versatility and performance, boasting a 4260 yard detection range as a dedicated thermal sight, or compatibility with day optics up to 10× as an inline clip-on sight. The combination of the HYBRID’s low-distortion orthoscopic eyepiece and a 1.03-inch large-format 2560×1920 display provides comfortable viewing as a dedicated sight while still maintaining the pixel density and resolution for use as a clip-on optic. The HYBRID also unlocks advanced features such as compatibility with a 1,000 yard laser rangefinder, a custom reticle generator, Bluetooth remote, and an onboard ballistic solver.



Advanced Long-Range Capabilities with f75mm/F1.0 Objective Lens



The Hybrid HYH75W redefines long-range detection with its f75mm/F1.0 objective lens, elevating your hunting capabilities. This precision-engineered lens significantly boosts the system's detection range, enabling clear and accurate target detection at distances up to 3896 meters (4260 yards). Ideal for demanding environments where distance and clarity are paramount, the HYH75W ensures superior performance in a variety of conditions.




Magnesium-Aluminum Alloy Body: Lightweight and Durable



The Hybrid HYH75W sets a new standard in material innovation with its magnesium-aluminum alloy body. This strategic material choice ensures the HYH75W retains exceptional durability and reliability, vital for rigorous field use. Despite its enhanced capabilities and size, the HYH75W astoundingly adds only about 90g more than its predecessor, the HYH50W. This lightweight design revolutionizes portability and ease of use without compromising on strength and stability. Experience the perfect balance of robustness and minimal weight with the HYH75W.


画板 2.png


2-in-1 Riflescope + Clip on



Hybrid supports both Riflescope and Clip-on Mode, allowing for seamless switching between the two modes in seconds without the need to change the eyepiece.


画板 3.png


Ultra Clear



Featuring a 2K-level display tailored for outdoor hunting, the high-resolution 2560×1920 silicon-based AMOLED display boasts high contrast and low power consumption. This technology delivers an ultra-clear and comfortable visual experience for users in the field.


画板 4.png


Ultra Precise



The Hybrid is equipped to utilize an external laser rangefinder, enabling precise aiming points through automatic ballistic calculation based on rangefinding results, achieving an accuracy of ±1 MOA. It allows for finer adjustments down to 1.2cm @100m during zeroing. Moreover, designed to accommodate different user preferences, the Hybrid offers 7 reticle patterns, ensuring versatility to meet varied aiming requirements.


画板 5.png


Extra Large Eyebox



The larger eyebox facilitates clear imaging in dynamic situations, while the 60mm long eye relief design prevents eye injuries caused by recoil when shooting.




More Amazing Features


640*48012µm Thermal Sensor | NETD<25mK | Shock Resistance | IP67 | LRF Supported | Ballistic Calculation

6 拷贝.png




Download

Brochure- HYH75W

Brochure- HYH75W
  • HYH75W
Model ParametersHYH75W
Detector640x480/12um
NETD25mK
Thermal Objective Lensf75/F1.0
FOV5.9°×4.4°
Visual magnification4x
Focal Length Range20m~
Detection Range (deer)3890m
Detection Range (vehicle)5270m
Digital zoom1x/2x/4x/8x
Recommended Day Scope Magnification1x-9x
Laser RangefindingSupport LR1000 and LR2000
Polaritywhite-hot,black-hot,red-hot,iron-red,rainbow,and outline
Eye relief25mm~60mm
Diopter-4D~+2D
Display1.03"2560x1920
Battery3.7V/4400mAh
Battery life6h
External Power SupplyDC5V (USB C)
Audio RecordingSupported
Memory capacity64G
Ingress protection ratingIP67
Impact Resistance1200g/0.3ms
Support .375 or 9.3×64
Operating Temperature-20~+50
Weight<1005g (with battery, without support)
Dimension310mm×105mm×91mm


  • Product Parameters Comparison
  • Model ParametersHYH75W
    Detector640x480/12um
    NETD25mK
    Thermal Objective Lensf75/F1.0
    FOV5.9°×4.4°
    Visual magnification4x
    Focal Length Range20m~
    Detection Range (deer)3890m
    Detection Range (vehicle)5270m
    Digital zoom1x/2x/4x/8x
    Recommended Day Scope Magnification1x-9x
    Laser RangefindingSupport LR1000 and LR2000
    Polaritywhite-hot,black-hot,red-hot,iron-red,rainbow,and outline
    Eye relief25mm~60mm
    Diopter-4D~+2D
    Display1.03"2560x1920
    Battery3.7V/4400mAh
    Battery life6h
    External Power SupplyDC5V (USB C)
    Audio RecordingSupported
    Memory capacity64G
    Ingress protection ratingIP67
    Impact Resistance1200g/0.3ms
    Support .375 or 9.3×64
    Operating Temperature-20~+50
    Weight<1005g (with battery, without support)
    Dimension310mm×105mm×91mm
