The compact & elegant design and easy operational functions make the Eye series thermal imaging monocular the ideal target observation tool in darkness.

Meet Eye Series V2.0


The compact & elegant design and easy operational functions make the Eye series thermal imaging monocular the idealvision enhancement tool in darkness.


High Image Quality

The Eye series are is embedded with IRay independently developed high performance VOx detector which allows you to get high detailed thermal images, so as to make it simpler to search targets in darkness.Comprised of advanced software algorithms EYE is designed to increase imaging clarity and overall image detail which results in a sharper, more detailed field of view and enhanced object identifcation capabilities.





Sufficient Operation Time

Low power elements used in Eye Series provide sufficient operation time. Up to 20 hours operational battery life guarantees you don't have to worry about the power supply.


Pocket-Sized Thermal Vision Monocular

The InfiRay EYE series is a pocket-sized thermal vision monocular for exploring the outdoors—at night and in lowlight conditions. EYE reveals your surroundings and helps you see people, objects and animals over hundreds meters away. Simple to use, with still image and video recording, EYE is the perfect companion, whether in the back country or your own backyard.The maximum weight is within 320g.


High Frame Rate

The 50Hz frame rate guarantees you to capture every moment that you want to catch. Smooth, fluent and crystal clear views offers excellent observation for all your outdoor adventures.


12μm Thermal Imaging Sensor

Eye V2 series products are rich in models and diversified choices, with two types of pixel sizes-12μm/17μm, multiple detector resolutions, and different types of lens focal lengths to meet the diverse needs of users.



Standby Function

When it is necessary to temporarily stop observation the user can apply standby function. It provides the necessary level of camouflage (no light from the eyepiece of the device) between observation sessions as well as the fast restart of observation (when display is turned off, all other systems are working; for normal operation it is enough just to power on the display again).



5 Color Palettes

The Eye V2 series provides 5 color palettes to achieve true color temperature mapping, including "white hot", "black hot", "red hot", "pseudo"and "hot target highlight". Switching between different color palettes is extremely simple and fast. Among them, the hot target highlight modecan make the high temperature target more obvious by improving the contrast between the highlight target and the surrounding environment.





Picture-in-Picture Function

Picture-in-Picture Function improves accuracy by providing a 2x magnified image of the reticle area at the top of the display. It helps to magnify the target while retaining the rest of the field of view visible.




Built-in Video Recorder and WiFi Connection

16GB memory is available for C2W/E3W, which can meet 40,000+ photos or 24 hours of continuous video recording,as much as possible to keep you the excitement of every moment of hunting.The built-in WiFi module allows 4 connections simultaneously.






Download

Brochure-E2n V2/E3n

Brochure-E2n V2/E3n

Brochure-C2W/E3W

Brochure-C2W/E3W

Manual-C2W/E3W

Manual-C2W/E3W

Manual-E2n V2/E3n

Manual-E2n V2/E3n
  • E2n
  • E6n
Detector Resolution240x180
Pixel Size17μm
NETD≤40mk
Frame Rate50Hz
Objective Lens13mm
Field of View17.8°x13.14°
Display Resolution720*540
E-zoom0.93-1.86
Max. Battery Life15h
Dimension, mm160×62×62
Weight<320g
Detection Range, m
(Targetsize:1.7m×0.5m, P(n)=99%)

476


Detector Resolution, Pixels640×512
Pixel Size, μm12
NETD, mK≤50
Objektiv, mm25mm
Frame Rate, Hz50
Display Resolution, Pixels720x540
Sichtfeld 17.5°x14°
Magnification, x0.95-3.8
Max. Battery Life, h12
Dimension, mm185x62x62
Weight, g≤400g
Detection Range, m (Target size: 1.7mx0.5m, P(n)=99%)1298



  • Product Parameters Comparison


  • ModelE3nE6n
    Detector Resolution, Pixels240×180640×512
    Pixel Size, μm1712
    NETD, mK≤40
    Objektiv, mm13mm25mm
    Frame Rate, Hz50
    Display Resolution, Pixels720x540
    Sichtfeld17.8°x13.4°17.5°x14°
    Magnification, x0.93-1.860.95-3.8
    Max. Battery Life, h1512
    Dimension, mm160x62x62185x62x62
    Weight, g≤320g≤400g
    Detection Range, m(Target size: 1.7mx0.5m, P(n)=99%)4761298
