Thermal Imaging Scope DV Series
Thermal Imaging Scope DV Series

Thermal Imaging Scope DV Series

Thermal Imaging Scope DV Series

The DV series can be used as a monocular thermal imaging scope or as an attachment to a mobile phone. When connecting to a phone, it can be used as a tool for real-time temperature measurement. With small size and weight of 89 g, the device is easy to be put in a pocket. It is small, but much powerful.

Meet DVSeries


The DV series can be used as a monocular thermal imaging scope or as an attachment to a mobile phone. When connecting to a phone, it can be used as a tool for real-time temperature measurement. With small size and weight of 89 g, the device is easy to be put in a pocket. It is small, but much powerful.



More Choice, More Fun

Monocular for hunting, tool for temperature measuring, thermal recording for sharing. Easy as a toy, take it and find more fun.


High Image Quality

Embedded with InfiRay, an outstanding 384×288 / 17 μm VOx detector, the DV series provides superb images and makes searching target much easier in the darkness.


High Frame Rate

25 Hz frame rate output is capable of capturing every wonderful moment during night viewing.


Remarkably Small and Portable

Weighing only89 g, it’s remarkably compact in size, and portable. Leave it in your pocket and you can have thermal viewing anywhere.


Excellent Plug Design

Just push the cover, the plug will pop out automatically.


Powerful APP

The APP supports thermal imaging video recording and shooting, offering real-time display of full-frame temperature measurement analysis and support for three areas ofpoint-line-surface temperature measurements.



Real-time Temperature Measurement Mode

The DV Thermal Imaging Scope is designed to deliver flawless performance at an extreme temperature range of -20℃ - +120℃. Under wide dynamic temperature measurement mode, the temperature measurement range is 120℃ - 400℃.


Low Power Consumption

With low power consumption design, it can operate for over 4 hours using one CR123 battery. Also it can be connected to a phone to extend its power supply.


Hot Target Tracking

High/low temperature spot tracking are supported at three points (Highhigh/Low low and central) of temperature measurements.

Download

Brochure-DV Series

Brochure-DV Series

Manual-DV Series

Manual-DV Series
  • DL13
  • DP09
Resolution384×288
PixelSize,μm17
NETD,mK≤60@25℃,F#1.0
MRTD,mK≤500@25℃,F#1.0
Frame Rate,Hz25
ObjectiveLens,mm13
Field ofView23.6°×20.7°
Magnification,×2001/2/4
BatteryCR123(3.7V)
Weight(without batteries),g<90
Dimension,mm77×56×36
PowerConsumption,mW800±100
InterfaceType-C


Resolution256X192
Pixel Size, μm12
NETD, mK≤60 @25℃,F#1.0
MRTD, mK≤500 @25℃,F#1.0
Frame Rate, Hz25
Objective Lens, mm9
Field of View19.6°×14.7°
Magnification, ×1/2
BatteryCR123 (3.7V)
Weight (without batteries), g<85
Dimension, mm77×56×36
Power Consumption, mW600±100
InterfaceType-C


  • Product Parameters Comparison
  • ModelDL13DP09
    Sensor Resolution, pixels384×288256X192
    PixelSize,μm1712
    NETD,mK≤60@25℃,F#1.0
    MRTD,mK≤500@25℃,F#1.0
    Frame Rate,Hz25
    ObjectiveLens,mm139
    Field ofView,°23.6°×20.7°19.6°×14.7°
    Magnification,×1/2/41/2
    Battery TypeCR123(3.7V)
    Weight(without batteries),g<90<85
    Dimension,mm77×56×36
    PowerConsumption,mW800±100600±100
    InterfaceType-C
