Thermal Imaging Riflescope Rico Series-RS75
Thermal Imaging Riflescope Rico Series-RS75

Thermal Imaging Riflescope Rico Series-RS75

Thermal Imaging Riflescope Rico Series-RS75

Rico-RS75 ushers in a whole new era of high-definition thermal with its most powerful thermal imaging detector. RS75 is the first to adopt a thermal imaging detector with a resolution up to 1280*1024. Every RICO with the 1280 detector will be transformed into a completely different class of product. Altogether with its 2560*2560, 1.03-inch AMOLED display, and optimized optical opponent, RS75 is designed to be the dream scope for night hunters.

Meet Rico Series-RS75

Rico-RS75 ushers in a whole new era of high-definition thermal with its most powerful thermal imaging detector. RS75 is the first to adopt a thermal imaging detector with a resolution up to 1280*1024. Every RICO with the 1280 detector will be transformed into a completely different class of product. Altogether with its 2560*2560, 1.03-inch AMOLED display, and optimized optical opponent, RS75 is designed to be the dream scope for night hunters.


First 1280 Resolution Sensor Product

The clarity is redefined with the 1280 detector. The image keeps incredible detail even at full 12x zoom, which 640 detectors cannot provide.


Detection Range Up to 3896m/4260yd

RS75 features a 75mm objective lens. The combination of insane focal length and the powerful detector expand the detection range to over 3800 meters.


Ultra-Clear Mode

Like the sport mode of the vehicle, RS75’s ultra-clear mode pushes the performance to the limit by temporally increasing consumption. Users can still see detailed images on rainy and foggy days with the facilitation of the ultra-precise mode.


Large HD Screen

RS75’s 2560*2560 1.03-inch AMOLED display can take the best advantage of the powerful detector and provide exquisite images as well as a comfortable visual experience.


Picture-in-Picture

The Picture-in-Picture function improves accuracy by providing a 2 x-magnified image of the reticle area, at the top of the display. It helps to magnify the target while maintaining visibility of the entire field of view.




Optimized Eyepiece

The optical design makes the image to be distortion-free at any angle. Altogether with the 60mm eye relief, the eyepiece can provide a better visual experience and effectively alleviate the dizziness arising from long-time observation.


LRF in Box

The standard configuration includes RICO LRF, which can accurately capture and display the target distance with an accuracy of ± 1 m and a maximum distance of 1000 m.


Worry-free Recording

The improved microphone makes the audio to be crystal clear. 128G internal memory enables users to store countless hours of footage.




Download

Brochure-RS75

Brochure-RS75

Manual-RS75

Manual-RS75
  • RS75
MODELRS75
TypeUncooled
Resolution, pixels1280×1024
Pixel Size, um12
NETD, mk≤25
Frame Rate, Hz30
Optical Characteristics
Objective Lens, mm75
Field of View, º11.7×9.4
Magnification, x
E-zoom, x2~32
Eye Relief, mm60
Diopter Adjustment, D-3 ~ +3
Display
TypeOLED
Resolution, pixels2560×2560
Operational Characteristics
Battery4400mAh
Max. Operating Time (at temp.=22 ºC), h*6h
External power supply5V (Type C USB)
Max. Recoil Power on Rifled Weapon, g/s²1000
Degree of protection, IP codeIP67
Amount of built-in memory, GB128
Operating Temperature Range, ℃-20~+50
Weight, g≤1200g
Dimension, mm319×100×85
USB InterfaceType-C
Detection Range, m (Target size:1.7m×0.5m, P(n)=99%)3896



  • Product Parameters Comparison
  • MODELRS75
    TypeUncooled
    Resolution, pixels1280×1024
    Pixel Size, um12
    NETD, mk≤25
    Frame Rate, Hz30
    Optical Characteristics
    Objective Lens, mm75
    Field of View, º11.7×9.4
    Magnification, x
    E-zoom, x2~32
    Eye Relief, mm60
    Diopter Adjustment, D-3 ~ +3
    Display
    TypeOLED
    Resolution, pixels2560×2560
    Operational Characteristics
    Battery4400mAh
    Max. Operating Time (at temp.=22 ºC), h*6h
    External power supply5V (Type C USB)
    Max. Recoil Power on Rifled Weapon, g/s²1000
    Degree of protection, IP codeIP67
    Amount of built-in memory, GB128
    Operating Temperature Range, ℃-20~+50
    Weight, g≤1200g
    Dimension, mm319×100×85
    USB InterfaceType-C
    Detection Range, m (Target size:1.7m×0.5m, P(n)=99%)3896
